ไฮไลท์
• A function to save personal data and measurement data to a Windows PC has been added by dedicated software.
• You can check the electrostatic shoes individually on the left and right.
• You can select the upper and lower limits of the judgment level.
• With the function of outputting the OK / NG judgment result to the outside and interlocking with the equipment, it is possible to unlock the electronic lock of the air shower room and activate the buzzer of the explosion-proof facility.
• In addition to keyboard input, personal data such as worker names and department names can also be input from QR codes using a commercially available barcode reader.
• Electrostatic shoes and wrist straps can be checked simultaneously or individually by setting the mode.
• If the measurement is not performed for a certain period of time, it automatically shifts to sleep mode.
ข้อมูล
น้ำหนัก
บาร์โค้ด
ลงสินค้า
อัพเดทล่าสุด
รายละเอียดสินค้า

specifications

Specifications / Standards
  • Wrist strap check function: Upper limit: 10MΩ Lower limit: 0.75MΩ
  • Shoe check function: Judgment setting values can be changed for both upper and lower limits (upper limit: 10MΩ, 100MΩ, 1000MΩ) (lower limit: 0.1MΩ, 1MΩ)
  • Width (mm): 200
  • Depth (mm): 40
  • Height (mm): 130
  • Shoe side electrode width (mm): 160
  • Judgment level accuracy: Less than 100MΩ ± 10% / 100MΩ or more ± 20%
  • Measurement time: Approximately 3 seconds
  • Measurement voltage: (shoes) DC24V, (wrist strap) DC10V
  • Maximum measured current (short circuit): 25 μA or less
  • Measurement mode: (all mode) shoe left → shoe right → wrist strap, (shoe mode) shoe left → shoe right, (wrist strap mode) wrist strap only
  • Specifications Temperature / humidity range: 0 ° C to 40 ° C 90% RH or less (however, no condensation)
  • Dimensions: (Measuring part) 200mm x 130mm x 40mm, (Shoe side electrode part) 350mm x 160mm x 35mm
  • Communication: USB B type (measurement data can be transferred to a Windows PC using dedicated communication data display software) * Communication data display software can be downloaded for free from the website only for purchasers.
  • Power supply: AC adapter (DC6V)
Material ――――
Mass / mass unit
  • 2.4kg
terms of use ――――
Precautions
  • It is not explosion-proof.
Set contents / accessories
  • AC adapter
Product number  MES-400
Order code  208-5218
JAN  4548890441443
